Florence 6 Column 12in
From: $709.50
Technical specs at 3 sections long:
| Length | Heat output (Hydronic) | ||
| Height | Heat output (Steam) | Not suitable for use on steam systems | |
| Depth | Delivered in |
- Available from 3 to 40 sections long (see below for technical specs)
- Delivered ready to install
- Heat pump compatible
- 10 year warranty
- Not suitable for steam
- Welded joins with powder coat finish
- Made in Italy
Model Specifications
| Label | Attribute | Value |
|---|---|---|
| A | Height With Legs | 15.8 in |
| B | Bottom Inlet To Floor | 5.3 in |
| C | Max Section Depth | 8.5 in |
| D | Interaxis Distance | 9.3 in |
| E | Height Without Legs | 11.9 in |
| F | Section Length | 1.8 in |
| G | Mid Section Depth | 8.5 in |
| - | Internal Volume | 0.30 gal |
| - | Empty Leg Section Weight | 3.75 lb |
| - | Empty Mid Section Weight | 3.09 lb |
| - | Heating medium | Hydronic, One-pipe steam, Two-pipe steam |
| - | EDR Per Section | 1.62 ft² |
| - | Hydronic Output (170ºF) | 244 BTUs |
| - | Steam Output (215ºF) | 390 BTUs |
Sizes Available
| SKU | N Secs |
Length (L, mm) |
Output (Hydronic, 170ºF) |
EDR | Delivery pieces |
Price from |
|---|---|---|---|---|---|---|
| SMC-F6C-302-3 | 3 | 6.5 in | 732 BTUs | 4.9 ft² | 1 | $709.50 |
| SMC-F6C-302-4 | 4 | 8.3 in | 976 BTUs | 6.5 ft² | 1 | $781.00 |
| SMC-F6C-302-5 | 5 | 10.0 in | 1220 BTUs | 8.1 ft² | 1 | $852.50 |
| SMC-F6C-302-6 | 6 | 11.8 in | 1464 BTUs | 9.7 ft² | 1 | $924.00 |
| SMC-F6C-302-7 | 7 | 13.6 in | 1708 BTUs | 11.3 ft² | 1 | $995.50 |
| SMC-F6C-302-8 | 8 | 15.4 in | 1952 BTUs | 13.0 ft² | 1 | $1,067.00 |
| SMC-F6C-302-9 | 9 | 17.1 in | 2196 BTUs | 14.6 ft² | 1 | $1,138.50 |
| SMC-F6C-302-10 | 10 | 18.9 in | 2440 BTUs | 16.2 ft² | 1 | $1,210.00 |
| SMC-F6C-302-11 | 11 | 20.7 in | 2684 BTUs | 17.8 ft² | 1 | $1,281.50 |
| SMC-F6C-302-12 | 12 | 22.4 in | 2928 BTUs | 19.4 ft² | 1 | $1,353.00 |
| SMC-F6C-302-13 | 13 | 24.2 in | 3172 BTUs | 21.1 ft² | 1 | $1,424.50 |
| SMC-F6C-302-14 | 14 | 26.0 in | 3416 BTUs | 22.7 ft² | 1 | $1,496.00 |
| SMC-F6C-302-15 | 15 | 27.8 in | 3660 BTUs | 24.3 ft² | 1 | $1,567.50 |
| SMC-F6C-302-16 | 16 | 29.5 in | 3904 BTUs | 25.9 ft² | 1 | $1,639.00 |
| SMC-F6C-302-17 | 17 | 31.3 in | 4148 BTUs | 27.5 ft² | 1 | $1,710.50 |
| SMC-F6C-302-18 | 18 | 33.1 in | 4392 BTUs | 29.2 ft² | 1 | $1,782.00 |
| SMC-F6C-302-19 | 19 | 34.8 in | 4636 BTUs | 30.8 ft² | 1 | $1,853.50 |
| SMC-F6C-302-20 | 20 | 36.6 in | 4880 BTUs | 32.4 ft² | 1 | $1,925.00 |
| SMC-F6C-302-21 | 21 | 38.4 in | 5124 BTUs | 34.0 ft² | 1 | $1,996.50 |
| SMC-F6C-302-22 | 22 | 40.2 in | 5368 BTUs | 35.6 ft² | 1 | $2,068.00 |
| SMC-F6C-302-23 | 23 | 41.9 in | 5612 BTUs | 37.3 ft² | 1 | $2,139.50 |
| SMC-F6C-302-24 | 24 | 43.7 in | 5856 BTUs | 38.9 ft² | 1 | $2,211.00 |
| SMC-F6C-302-25 | 25 | 45.5 in | 6100 BTUs | 40.5 ft² | 1 | $2,282.50 |
| SMC-F6C-302-26 | 26 | 47.2 in | 6344 BTUs | 42.1 ft² | 1 | $2,354.00 |
| SMC-F6C-302-27 | 27 | 49.0 in | 6588 BTUs | 43.7 ft² | 1 | $2,425.50 |
| SMC-F6C-302-28 | 28 | 50.8 in | 6832 BTUs | 45.4 ft² | 1 | $2,497.00 |
| SMC-F6C-302-29 | 29 | 52.6 in | 7076 BTUs | 47.0 ft² | 1 | $2,568.50 |
| SMC-F6C-302-30 | 30 | 54.3 in | 7320 BTUs | 48.6 ft² | 1 | $2,640.00 |
| SMC-F6C-302-31 | 31 | 56.1 in | 7564 BTUs | 50.2 ft² | 1 | $2,711.50 |
| SMC-F6C-302-32 | 32 | 57.9 in | 7808 BTUs | 51.8 ft² | 1 | $2,783.00 |
| SMC-F6C-302-33 | 33 | 59.6 in | 8052 BTUs | 53.5 ft² | 1 | $2,854.50 |
| SMC-F6C-302-34 | 34 | 61.4 in | 8296 BTUs | 55.1 ft² | 1 | $2,926.00 |
| SMC-F6C-302-35 | 35 | 63.2 in | 8540 BTUs | 56.7 ft² | 1 | $2,997.50 |
| SMC-F6C-302-36 | 36 | 65.0 in | 8784 BTUs | 58.3 ft² | 1 | $3,069.00 |
| SMC-F6C-302-37 | 37 | 66.7 in | 9028 BTUs | 59.9 ft² | 1 | $3,140.50 |
| SMC-F6C-302-38 | 38 | 68.5 in | 9272 BTUs | 61.6 ft² | 1 | $3,212.00 |
| SMC-F6C-302-39 | 39 | 70.3 in | 9516 BTUs | 63.2 ft² | 1 | $3,283.50 |
| SMC-F6C-302-40 | 40 | 72.0 in | 9760 BTUs | 64.8 ft² | 1 | $3,355.00 |
