Florence 5 Column 200mm

From: £276.60

Technical specs at 3 sections long:

Length
Heat output (∆T50)
Height
Pipe centres
Depth
Delivered in
  • Available from 3 to 40 sections long (see below for technical specs)
  • Delivered ready to install
  • Heat pump compatible
  • 10 year warranty
  • Not suitable for steam
  • Welded joins with powder coat finish
  • Made in Italy
SKU: SMC-F5C-194

Model Specifications

Label Attribute Value
A Height With Legs (mm) 294
B Bottom Inlet To Floor (mm) 134
C Max Section Depth (mm) 179
D Interaxis Distance (mm) 1935
E Height Without Legs (mm) 194
- Output (ΔT50, W) 31.7
F Section Length (mm) 45
- Output (ΔT30, W) 15.9
G Mid Section Depth (mm) 177
- Internal Volume (L) 0.73
- Empty Leg Section Weight (kg) 1.1
- Empty Mid Section Weight (kg) 0.8
- Factor, Km 0.161
- Exponent, n 1.35025
- Heating medium Hydronic, One-pipe steam, Two-pipe steam
Florence 5 Column 200mm - Single Section Technical Drawing - SVG

Sizes Available

83833
83833
83833
83833
83833
83833
83833
83833
83833
83833
83833
83833
83833
83833
83833
83833
83833
83833
83833
83833
83833
83833
83833
83833
83833
83833
83833
83833
83833
83833
83833
83833
83833
83833
83833
83833
83833
83833
SKU N
Secs
Length
(L, mm)
Output
(∆T50, Watts)
Output
(∆T30, Watts)
Delivery
pieces
Price
from
SMC-F5C-194-3 3 165 95 47 1 £276.60
SMC-F5C-194-4 4 210 126 63 1 £322.80
SMC-F5C-194-5 5 255 158 79 1 £369.00
SMC-F5C-194-6 6 300 190 95 1 £415.20
SMC-F5C-194-7 7 345 221 111 1 £461.40
SMC-F5C-194-8 8 390 253 127 1 £507.60
SMC-F5C-194-9 9 435 285 143 1 £553.80
SMC-F5C-194-10 10 480 317 159 1 £600.00
SMC-F5C-194-11 11 525 348 174 1 £646.20
SMC-F5C-194-12 12 570 380 190 1 £692.40
SMC-F5C-194-13 13 615 412 206 1 £738.60
SMC-F5C-194-14 14 660 443 222 1 £784.80
SMC-F5C-194-15 15 705 475 238 1 £831.00
SMC-F5C-194-16 16 750 507 254 1 £877.20
SMC-F5C-194-17 17 795 538 270 1 £923.40
SMC-F5C-194-18 18 840 570 286 1 £969.60
SMC-F5C-194-19 19 885 602 302 1 £1,015.80
SMC-F5C-194-20 20 930 634 318 1 £1,062.00
SMC-F5C-194-21 21 975 665 333 1 £1,108.20
SMC-F5C-194-22 22 1020 697 349 1 £1,154.40
SMC-F5C-194-23 23 1065 729 365 1 £1,200.60
SMC-F5C-194-24 24 1110 760 381 1 £1,246.80
SMC-F5C-194-25 25 1155 792 397 1 £1,293.00
SMC-F5C-194-26 26 1200 824 413 1 £1,339.20
SMC-F5C-194-27 27 1245 855 429 1 £1,385.40
SMC-F5C-194-28 28 1290 887 445 1 £1,431.60
SMC-F5C-194-29 29 1335 919 461 1 £1,477.80
SMC-F5C-194-30 30 1380 951 477 1 £1,524.00
SMC-F5C-194-31 31 1425 982 492 1 £1,570.20
SMC-F5C-194-32 32 1470 1014 508 1 £1,616.40
SMC-F5C-194-33 33 1515 1046 524 1 £1,662.60
SMC-F5C-194-34 34 1560 1077 540 1 £1,708.80
SMC-F5C-194-35 35 1605 1109 556 1 £1,755.00
SMC-F5C-194-36 36 1650 1141 572 1 £1,801.20
SMC-F5C-194-37 37 1695 1172 588 1 £1,847.40
SMC-F5C-194-38 38 1740 1204 604 1 £1,893.60
SMC-F5C-194-39 39 1785 1236 620 1 £1,939.80
SMC-F5C-194-40 40 1830 1268 636 1 £1,986.00
Florence 5 Column 200mm - 10 Section Battery Technical Drawing - SVG
