Florence 3 Column 2200mm

From: £478.20

Technical specs at 3 sections long:

Length
Heat output (∆T50)
Height
Pipe centres
Depth
Delivered in
  • Available from 3 to 40 sections long (see below for technical specs)
  • Delivered ready to install
  • Heat pump compatible
  • 10 year warranty
  • Not suitable for steam
  • Welded joins with powder coat finish
  • Made in Italy
SKU: SMC-F3C-2202

Model Specifications

Label Attribute Value
A Height With Legs (mm) 2302
B Bottom Inlet To Floor (mm) 134
C Max Section Depth (mm) 103
D Interaxis Distance (mm) 2135
E Height Without Legs (mm) 2202
- Output (ΔT50, W) 205.7
F Section Length (mm) 45
- Output (ΔT30, W) 105.3
G Mid Section Depth (mm) 101
- Internal Volume (L) 2.92
- Empty Leg Section Weight (kg) 4.6
- Empty Mid Section Weight (kg) 4.3
- Factor, Km 1.2217
- Exponent, n 1.31033
- Heating medium Hydronic, One-pipe steam, Two-pipe steam
Florence 3 Column 2200mm - Single Section Technical Drawing - SVG

Sizes Available

83804
83804
83804
83804
83804
83804
83804
83804
83804
83804
83804
83804
83804
83804
83804
83804
83804
83804
83804
83804
83804
83804
83804
83804
83804
83804
83804
83804
83804
83804
83804
83804
83804
83804
83804
83804
83804
83804
SKU N
Secs
Length
(L, mm)
Output
(∆T50, Watts)
Output
(∆T30, Watts)
Delivery
pieces
Price
from
SMC-F3C-2202-3 3 165 617 315 1 £478.20
SMC-F3C-2202-4 4 210 822 421 1 £591.60
SMC-F3C-2202-5 5 255 1028 526 1 £705.00
SMC-F3C-2202-6 6 300 1234 631 1 £818.40
SMC-F3C-2202-7 7 345 1439 737 1 £931.80
SMC-F3C-2202-8 8 390 1645 842 1 £1,045.20
SMC-F3C-2202-9 9 435 1851 947 1 £1,158.60
SMC-F3C-2202-10 10 480 2057 1053 1 £1,272.00
SMC-F3C-2202-11 11 525 2262 1158 1 £1,385.40
SMC-F3C-2202-12 12 570 2468 1263 1 £1,498.80
SMC-F3C-2202-13 13 615 2674 1368 1 £1,612.20
SMC-F3C-2202-14 14 660 2879 1474 1 £1,725.60
SMC-F3C-2202-15 15 705 3085 1579 1 £1,839.00
SMC-F3C-2202-16 16 750 3291 1684 1 £1,952.40
SMC-F3C-2202-17 17 795 3496 1790 1 £2,065.80
SMC-F3C-2202-18 18 840 3702 1895 1 £2,179.20
SMC-F3C-2202-19 19 885 3908 2000 1 £2,292.60
SMC-F3C-2202-20 20 930 4114 2106 1 £2,406.00
SMC-F3C-2202-21 21 975 4319 2211 1 £2,519.40
SMC-F3C-2202-22 22 1020 4525 2316 1 £2,632.80
SMC-F3C-2202-23 23 1065 4731 2421 1 £2,746.20
SMC-F3C-2202-24 24 1110 4936 2527 1 £2,859.60
SMC-F3C-2202-25 25 1155 5142 2632 1 £2,973.00
SMC-F3C-2202-26 26 1200 5348 2737 1 £3,086.40
SMC-F3C-2202-27 27 1245 5553 2843 1 £3,199.80
SMC-F3C-2202-28 28 1290 5759 2948 1 £3,313.20
SMC-F3C-2202-29 29 1335 5965 3053 1 £3,426.60
SMC-F3C-2202-30 30 1380 6171 3159 1 £3,540.00
SMC-F3C-2202-31 31 1425 6376 3264 1 £3,653.40
SMC-F3C-2202-32 32 1470 6582 3369 1 £3,766.80
SMC-F3C-2202-33 33 1515 6788 3474 1 £3,880.20
SMC-F3C-2202-34 34 1560 6993 3580 1 £3,993.60
SMC-F3C-2202-35 35 1605 7199 3685 1 £4,107.00
SMC-F3C-2202-36 36 1650 7405 3790 1 £4,220.40
SMC-F3C-2202-37 37 1695 7610 3896 1 £4,333.80
SMC-F3C-2202-38 38 1740 7816 4001 1 £4,447.20
SMC-F3C-2202-39 39 1785 8022 4106 1 £4,560.60
SMC-F3C-2202-40 40 1830 8228 4212 1 £4,674.00
Florence 3 Column 2200mm - 10 Section Battery Technical Drawing - SVG
