Florence 2 Column 2000mm

From: £348.60

Technical specs at 3 sections long:

Length
Heat output (∆T50)
Height
Pipe centres
Depth
Delivered in
  • Available from 3 to 40 sections long (see below for technical specs)
  • Delivered ready to install
  • Heat pump compatible
  • 10 year warranty
  • Not suitable for steam
  • Welded joins with powder coat finish
  • Made in Italy
SKU: SMC-F2C-2002

Model Specifications

Label Attribute Value
A Height With Legs (mm) 2102
B Bottom Inlet To Floor (mm) 134
C Max Section Depth (mm) 67
D Interaxis Distance (mm) 127
E Height Without Legs (mm) 2002
- Output (ΔT50, W) 139
F Section Length (mm) 45
- Output (ΔT30, W) 70.9
G Mid Section Depth (mm) 65
- Internal Volume (L) 1.8
- Empty Leg Section Weight (kg) 3
- Empty Mid Section Weight (kg) 2.7
- Factor, Km 0.7983
- Exponent, n 1.31894
- Heating medium Hydronic, One-pipe steam, Two-pipe steam
Florence 2 Column 2000mm - Single Section Technical Drawing - SVG

Sizes Available

83787
83787
83787
83787
83787
83787
83787
83787
83787
83787
83787
83787
83787
83787
83787
83787
83787
83787
83787
83787
83787
83787
83787
83787
83787
83787
83787
83787
83787
83787
83787
83787
83787
83787
83787
83787
83787
83787
SKU N
Secs
Length
(L, mm)
Output
(∆T50, Watts)
Output
(∆T30, Watts)
Delivery
pieces
Price
from
SMC-F2C-2002-3 3 165 417 212 1 £348.60
SMC-F2C-2002-4 4 210 556 283 1 £418.80
SMC-F2C-2002-5 5 255 695 354 1 £489.00
SMC-F2C-2002-6 6 300 834 425 1 £559.20
SMC-F2C-2002-7 7 345 973 496 1 £629.40
SMC-F2C-2002-8 8 390 1112 567 1 £699.60
SMC-F2C-2002-9 9 435 1251 638 1 £769.80
SMC-F2C-2002-10 10 480 1390 709 1 £840.00
SMC-F2C-2002-11 11 525 1529 779 1 £910.20
SMC-F2C-2002-12 12 570 1668 850 1 £980.40
SMC-F2C-2002-13 13 615 1807 921 1 £1,050.60
SMC-F2C-2002-14 14 660 1946 992 1 £1,120.80
SMC-F2C-2002-15 15 705 2085 1063 1 £1,191.00
SMC-F2C-2002-16 16 750 2224 1134 1 £1,261.20
SMC-F2C-2002-17 17 795 2363 1205 1 £1,331.40
SMC-F2C-2002-18 18 840 2502 1276 1 £1,401.60
SMC-F2C-2002-19 19 885 2641 1347 1 £1,471.80
SMC-F2C-2002-20 20 930 2780 1418 1 £1,542.00
SMC-F2C-2002-21 21 975 2919 1488 1 £1,612.20
SMC-F2C-2002-22 22 1020 3058 1559 1 £1,682.40
SMC-F2C-2002-23 23 1065 3197 1630 1 £1,752.60
SMC-F2C-2002-24 24 1110 3336 1701 1 £1,822.80
SMC-F2C-2002-25 25 1155 3475 1772 1 £1,893.00
SMC-F2C-2002-26 26 1200 3614 1843 1 £1,963.20
SMC-F2C-2002-27 27 1245 3753 1914 1 £2,033.40
SMC-F2C-2002-28 28 1290 3892 1985 1 £2,103.60
SMC-F2C-2002-29 29 1335 4031 2056 1 £2,173.80
SMC-F2C-2002-30 30 1380 4170 2127 1 £2,244.00
SMC-F2C-2002-31 31 1425 4309 2197 1 £2,314.20
SMC-F2C-2002-32 32 1470 4448 2268 1 £2,384.40
SMC-F2C-2002-33 33 1515 4587 2339 1 £2,454.60
SMC-F2C-2002-34 34 1560 4726 2410 1 £2,524.80
SMC-F2C-2002-35 35 1605 4865 2481 1 £2,595.00
SMC-F2C-2002-36 36 1650 5004 2552 1 £2,665.20
SMC-F2C-2002-37 37 1695 5143 2623 1 £2,735.40
SMC-F2C-2002-38 38 1740 5282 2694 1 £2,805.60
SMC-F2C-2002-39 39 1785 5421 2765 1 £2,875.80
SMC-F2C-2002-40 40 1830 5560 2836 1 £2,946.00
Florence 2 Column 2000mm - 10 Section Battery Technical Drawing - SVG
